KR-650 Export

Bruns; Hamburg

  • Year
  • 1983
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 178710

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 14
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Tuned circuits
  • 5 AM circuit(s)     8 FM circuit(s)
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 6 x 1,5 Volt
  • Power out
  • 1.5 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: KR-650 [Export] - Bruns; Hamburg
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 370 x 194 x 82 mm / 14.6 x 7.6 x 3.2 inch
  • Notes
  • Bei Stern Radio Berlin für Bruns produziert. Unterscheidet sich durch veränderte Skalenbeschriftung, andere Beschriftungen am Gehäuse, kein Bandzählwert, dafür Abdeckung mit Markennamen. Kein Hinweis auf DDR-Identität.
    Schwesternmodell KR650 von Stern Radio Berlin.
  • Net weight (2.2 lb = 1 kg)
  • 3.5 kg / 7 lb 11.3 oz (7.709 lb)
  • Source of data
  • - - Data from my own collection
  • Author
  • Model page created by Berthold Grenz. See "Data change" for further contributors.
