• Country
• Germany

• Manufacturer / Brand
• Bruns; Hamburg

• Year
• 1973

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 80060

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 5 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: Prominent 204 - Bruns; Hamburg

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 500 x 150 x 150 mm / 19.7 x 5.9 x 5.9 inch

• Notes
• Exportvariante des Prominent 204 von Stern-Radio Sonneberg, Holzgehäuse mit Plastikfront, UKW bis 108 MHz, Anschlüsse für TA/TB, Zweitlautsprecher, für AM Ferritantenne, für FM zwei Antenneneingänge für Außenantenne,

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Mario Coelho. See "Data change" for further contributors.
