• Country
• Germany

• Manufacturer / Brand
• Bruns; Hamburg

• Year
• 1968

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 99808

• Number of Transistors
• 11

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 4 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Storage and/or dry batteries / 2 × 4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 120 cm = 47.2 inch

• Power out
• 1 W (unknown quality)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: S-6000 - Bruns; Hamburg

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 294 x 235 x 100 mm / 11.6 x 9.3 x 3.9 inch

• Notes
• 6 Dioden; Anschschlüsse für TA/TB, Zusatzlautsprecher, Ohrhörer. Das Gerät ist die Exportversion des Sonneberg 6000, hergestellt von Stern-Radio Sonneberg, VEB, RFT, -vorm.: SONRA ; EAK (Ostd.) - ex. AEG

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Peter Lokowand. See "Data change" for further contributors.
