MK25; Budapesti (ID = 338888) R-Player
Budapesti: MK25 [R-Player] ID = 338888 504x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model MK25, Budapesti Rádiótechnikai Gyár (BRG):
Bild von nobody, vielen dank

Country:  Hungary
Manufacturer / Brand:  Budapesti Rádiótechnikai Gyár (BRG)
Year: 1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 8:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: MK25 - Budapesti Rádiótechnikai Gyár
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 235 x 68 x 200 mm / 9.3 x 2.7 x 7.9 inch
Notes Mono-Kassettengerät, Übertrgaungsbereich: 200···8000 Hz. Eingänge: Mikrofon, Plattenspieler, Radio. Überspielausgang, Ausgangsleistung: 0,4 Watt Musikleistung bei 10 % Klirrfaktor. Technisch gleich MK 26 aber mit Netzteil.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 1'800.00 HUF
Collectors' prices
Mentioned in -- Original prospect or advert (Die Geschichte der Fonoindustrie der DDR (B.4))
Literature/Schematics (1) Magnetofony 2, 1971-1975, Bozdech J.
Literature/Schematics (4) Rádiótechnika 1972/12.
Documents about this model
  Servicemitteilung 6/73 529 KB

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Budapesti Rádiótechnikai Gyár (BRG)
Here you find 79 models, 64 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
