All Button Receiver PB50

All Button Receiver PB50; Bush Radio; London (ID = 151476) Radio

All Button Receiver PB50; Bush Radio; London (ID = 151504) Radio

All Button Receiver PB50; Bush Radio; London (ID = 151485) Radio

All Button Receiver PB50; Bush Radio; London (ID = 151505) Radio

All Button Receiver PB50; Bush Radio; London (ID = 2407571) Radio

All Button Receiver PB50; Bush Radio; London (ID = 2407573) Radio
All Button Receiver PB50; Bush Radio; London (ID = 2115164) Radio All Button Receiver PB50; Bush Radio; London (ID = 151436) Radio
All Button Receiver PB50; Bush Radio; London (ID = 2115165) Radio All Button Receiver PB50; Bush Radio; London (ID = 2115166) Radio
Use red slider bar for more.
All Button Receiver PB50; Bush Radio; London (ID = 2115164) Radio
Bush Radio; London: All Button Receiver PB50 [Radio] ID = 2115164 1024x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model All Button Receiver PB50, Bush Radio; London:
Ebay UK auction item no. 182579008826 seller jpcollectables-jpcollectables

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TH4A VP4B TDD4 PenA4 DW4/350
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: All Button Receiver PB50 - Bush Radio; London
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 16.5 x 14.5 x 9.75 inch / 419 x 368 x 248 mm
Notes Eight pushbuttons for preset radio stations (no manual tuning!).
Source of data Radio! Radio!
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from Bush Radio; London
Here you find 343 models, 270 with images and 228 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
