BV5670

BV5670; Bush Radio; London (ID = 2307189) Radio

BV5670; Bush Radio; London (ID = 2307161) Radio

BV5670; Bush Radio; London (ID = 2307162) Radio

BV5670; Bush Radio; London (ID = 2307163) Radio

BV5670; Bush Radio; London (ID = 2307164) Radio

BV5670; Bush Radio; London (ID = 2307159) Radio

BV5670; Bush Radio; London (ID = 2307160) Radio
Use red slider bar for more.
BV5670; Bush Radio; London (ID = 2307189) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1976 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF195 BF195 BF194 BF195 BF195 BF195 BC158 BC158 AC188 AC188
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: BV5670 - Bush Radio; London
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Sockets for earphone and 6 volt PSU.

Eight diodes, including varicap for AFC.

Circuit diagram reference Radio and TV Servicing books (R&TVS) book
Mentioned in Radio And Television Servicing books (R&TVS) (1978-79 edition)
Literature/Schematics (1) ERT Service Chart 2132

Model page created by Howard Craven. See "Data change" for further contributors.
