Discassette DC70

Discassette DC70; Bush Radio; London (ID = 2036980) R-Player Discassette DC70; Bush Radio; London (ID = 2036982) R-Player
Discassette DC70; Bush Radio; London (ID = 2036983) R-Player Discassette DC70; Bush Radio; London (ID = 2036984) R-Player
Discassette DC70; Bush Radio; London (ID = 2036985) R-Player Discassette DC70; Bush Radio; London (ID = 2036986) R-Player
Discassette DC70; Bush Radio; London (ID = 2036987) R-Player Discassette DC70; Bush Radio; London (ID = 2036988) R-Player
Discassette DC70; Bush Radio; London (ID = 2036989) R-Player Discassette DC70; Bush Radio; London (ID = 2036991) R-Player
Use red slider bar for more.
Discassette DC70; Bush Radio; London (ID = 2036980) R-Player
Bush Radio; London: Discassette DC70 [R-Player] ID = 2036980 792x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Discassette DC70, Bush Radio; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1971 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6:
Main principle Audio-Amplification
Wave bands - without
Details Record Player + Tape Recorder
Power type and voltage Dry Batteries / UM2: 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Discassette DC70 - Bush Radio; London
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 8 x 7.5 x 3.5 inch / 203 x 191 x 89 mm
Notes

An unusual 45 rpm single disc player that will work in any position the same design as a Discatron but with the usefull adition of a built in Cassette player

Price in first year of sale 21.19 £
Mentioned in - - Manufacturers Literature

Model page created by Nigel Robinson. See "Data change" for further contributors.
