Sandpiper VTR127

Sandpiper VTR127; Bush Radio; London (ID = 2306765) Radio

Sandpiper VTR127; Bush Radio; London (ID = 2306766) Radio

Sandpiper VTR127; Bush Radio; London (ID = 2306767) Radio

Sandpiper VTR127; Bush Radio; London (ID = 2306768) Radio

Sandpiper VTR127; Bush Radio; London (ID = 490552) Radio

Sandpiper VTR127; Bush Radio; London (ID = 490553) Radio

Sandpiper VTR127; Bush Radio; London (ID = 490554) Radio

Sandpiper VTR127; Bush Radio; London (ID = 490556) Radio
Use red slider bar for more.
Sandpiper VTR127; Bush Radio; London (ID = 2306765) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: 2SC461 2SC535 2SA350 2SA350 2SA234 2SA353 2SB75 2SB75 2SB77 2SB77
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / C: 3 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.22 W (unknown quality)
from Radiomuseum.org Model: Sandpiper VTR127 - Bush Radio; London
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 8.875 x 5.5 x 2.625 inch / 225 x 140 x 67 mm
Notes

A ten transistor battery portable AM/FM radio covering MW (187 - 595 metres), LW (970 - 2140 metres) and VHF (87.3 - 104.5 MHz). Socket for earphone. Elliptical loudspeaker 5 x 3 inch.

Net weight (2.2 lb = 1 kg) 2 lb 4 oz (2.25 lb) / 1.022 kg
Price in first year of sale 17.50 GBP
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) ERT Service Chart 1793 dated May 27 1971

Model page created by Howard Craven. See "Data change" for further contributors.
