SB4

SB4; Bush Radio; London (ID = 1015312) Radio

SB4; Bush Radio; London (ID = 1015313) Radio

SB4; Bush Radio; London (ID = 1015314) Radio
Use red slider bar for more.
SB4; Bush Radio; London (ID = 1015312) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: FC2 VP2 TDD2 PM22A
Main principle Superheterodyne (common); ZF/IF 123 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 2 & 144 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: SB4 - Bush Radio; London
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader sheet 43

Model page created by Peter Hoddow. See "Data change" for further contributors.
