• Country
• Great Britain (UK)

• Manufacturer / Brand
• Bush Radio; London

• Year
• 1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 90248

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• BF194 BF194 BF194 BC148 BC153 AC127 AC128

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 4 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 5.38 inch = 13.7 cm

• Power out
• 0.45 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TR168 - Bush Radio; London

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 245 x 145 x 60 mm / 9.6 x 5.7 x 2.4 inch

• Notes
• Elliptical loudspeaker 5.375 x 2.75 inch.

• Net weight (2.2 lb = 1 kg)
• 0.9 kg / 1 lb 15.7 oz (1.982 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• Trader sheet 3021

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
