For model VHF102, Bush Radio; London:
Ebay UK item 142786321994 seller the-vintage-room

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF222 BF222 BF273 BF274 BF273 BC153 BC132 BC119 AD162 AD161
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 200-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 6 cm = 2.4 inch
Power out 10 W (unknown quality)
from Radiomuseum.org Model: VHF102 - Bush Radio; London
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 18.8125 x 8.625 x 6.75 inch / 478 x 219 x 171 mm
Notes

An AC mains powered AM/FM 10 transistor table radio covering MW (187 - 570 metres), LW (1070 - 1900 metres) and VHF (88 - 108 MHz). The radio is housed in a sealed wooden case which forms an acoustic chamber or 'Sealed Sound System'. DIN socket for output to tape recorder, and input from tape recorder playback or record player. Connectors for an external FM aerial. Elliptical loudspeaker 6 x 4 inch.

Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Price in first year of sale 45.38 GBP
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) ERT Service Chart 1807 dated September 2 1971

Model page created by Howard Craven. See "Data change" for further contributors.
