VTR265

VTR265; Bush Radio; London (ID = 2302005) Radio

VTR265; Bush Radio; London (ID = 2302006) Radio

VTR265; Bush Radio; London (ID = 2302007) Radio

VTR265; Bush Radio; London (ID = 2302008) Radio

VTR265; Bush Radio; London (ID = 2302009) Radio

VTR265; Bush Radio; London (ID = 2302010) Radio

VTR265; Bush Radio; London (ID = 2302011) Radio

VTR265; Bush Radio; London (ID = 2302012) Radio
Use red slider bar for more.
VTR265; Bush Radio; London (ID = 2302005) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Bush Radio; London
Year: 1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: 2SC1359 2SC1359 2SC829 2SC1359 2SC829 2SC829 2SC828 2SC828 2SB324G 2SB324G 2SB324
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 240 / C: 6 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: VTR265 - Bush Radio; London
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 308 x 170 x 90 mm / 12.1 x 6.7 x 3.5 inch
Notes

Elliptical loudspeaker 6 x 4 inch. The Murphy MV5702 has the same chassis.

Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Literature/Schematics (1) -- Original-techn. papers. (Bush Murphy Service Information TP1876 dated 1/8/74)

Model page created by Howard Craven. See "Data change" for further contributors.
