• Country
• India

• Manufacturer / Brand
• BUSH Limited India; Bombay

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 332764

• Number of Tubes
• 5

• Valves / Tubes
• UCH81 UF89 UL84 UY85 UM80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• AC/DC-set / 40-100 Hz or DC: 220-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Bonus EBS 143 - BUSH Limited India; Bombay

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 13 x 9 x 7 inch / 330 x 229 x 178 mm

• Notes

• "Manufactured by a company in association with the Rank Organisation."

• Net weight (2.2 lb = 1 kg)
• 4.5 kg / 9 lb 14.6 oz (9.912 lb)

• Author
• Model page created by Uday Kalburgi. See "Data change" for further contributors.

• Other Models

• Here you find 4 models, 4 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
