• Country
• Canada

• Manufacturer / Brand
• Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

• Year
• 1939 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 298921

• • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6K8 6K7 6Q7 6F6G 6U5 5Y4G

• Main principle
• Superhet with RF-stage; ZF/IF 462.5 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm

• Power out
• 1.7 W (4 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 167 - Canadian Marconi Co. Ltd. CMC,

• Shape
• Tablemodel with Push Buttons.

• Notes

• The Canadian Marconi model 167 is a 6-tube table radio with tuning eye tube and pushbutton station selector. Covers the following ranges:

  Band	Frequency (kHz)
  Standard Broadcast	535 - 1725
  49m	5950 - 6250
  31m	9450 - 9750
  25m	11650 - 11950
  19m	15050 - 15410

• Literature/Schematics (1)
• Marconi Service Manual (Volume 1) (P. 381-384)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
