For model 230, Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

Country:  Canada
Manufacturer / Brand:  Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
alternative name

CMC Canada || Marconi, Canada
Year: 1950 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1T4 1S5 1S4
Main principle Superheterodyne (common); ZF/IF 462.5 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 1.5 & 2 x 45 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out 0.11 W (unknown quality)
from Radiomuseum.org Model: 230 - Canadian Marconi Co. Ltd. CMC,
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Notes The Marconi Model 230 is a battery operated 4 Tube BC Receiver. BC Band Tuning Range: 540 to 1700kHz. Cabinet colors are Beige or Mahogany.
Mentioned in -- Original-techn. papers. (Canadian Marconi Co.; Techn. Data & Parts List,)
Literature/Schematics (1) Marconi Service Manual Volume No. 2 (Volume 2, Page 87)
Literature/Schematics (2) Radio College of Canada (RCC) (RCC Circuit Manual 1947-48 Part 2 Marconi Data Sheet # 138)

Model page created by a member from A. See "Data change" for further contributors.
