- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1952 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 215204
-
- alternative name: CMC Canada || Marconi, Canada
Picture from Marconi Radio service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 462.5/10700 kHz; 2 AF stage(s)
- Tuned circuits
- 8 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Power out
- 2.75 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 254FM - Canadian Marconi Co. Ltd. CMC,
- Shape
- Tablemodel, low profile (big size).
- Notes
- The Marconi Model 254FM is an AC operated 9 Tube BC/FM Receiver.
BC Band Tuning Range: 540 to 1720kHz.
FM Band Tuning Range: 88 to 108 MHz.
Operates with either 25 or 60Hz AC power. Has sound input jack for phonograph or TV. Marconi Console Model 255FM uses the same chassis and schematic but also has built-in phonograph.
- Literature/Schematics (1)
- Marconi Service Manual Volume No. 2 (Volume 2, Page 131)
