• Year
  • 1948 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 296338

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Details
  • Record Player (perh.Changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 105 - 125 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Automatic Record Changer CP5 - Canadian General Electric
  • Shape
  • Chassis only or for «building in»
  • Notes
  • The Canadian General Electric model CP5 is a 78 RPM record changer with magnetic pickup and is used in model C502 and other console models. Capacity is twelve 10 inch records or ten 12 inch records.

    For 25 or 60 Hz depending on nameplate rating.

  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
