- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1946/1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 94161
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 inch = 16.5 cm
- Power out
- 1.25 W (2 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C-106 - Canadian General Electric
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 18.3 x 9.4 x 13.8 inch / 465 x 239 x 351 mm
- Notes
-
Beam-a-scope antenna.
Mahogany finish wood cabinet. Turntable speed is 78 rpm. Crystal pickup.
- Mentioned in
- General Electric Radio and Television Service Manual 1945-1949 (Pages 72-74)
- Literature/Schematics (1)
- Radio College of Canada, Individual Circuit Service, 1927-1953
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
