• Year
  • 1948/1949
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 94567

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superhet with RF-stage; ZF/IF 460/10700 kHz; 2 AF stage(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • AC/DC-set / 105-125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
  • Power out
  • 1.2 W (2 W max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: C-356 - Canadian General Electric
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 13.75 x 8.37 x 7.75 inch / 349 x 213 x 197 mm
  • Notes
  • The Canadian General Electric model C-356 is an 8 tube AM/FM table radio. The cabinet is Mahogany colour plastic.The radio uses an internal loop antenna for AM reception. For FM it uses the power cord as an antenna. The pilot lamps are Mazda No. 47.



  • Literature/Schematics (1)
  • Radio College of Canada, Individual Circuit Service, 1927-1953
  • Author
  • Model page created by Vitor Oliveira. See "Data change" for further contributors.
