• Country
• Canada

• Manufacturer / Brand
• Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON

• Year
• 1949

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 289679

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 12SK7 12BE6 12SK7 12SQ7 35L6GT 35Z5GT

• Main principle
• Superhet with RF-stage; ZF/IF 460 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 0.8 W (1.4 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: C-604 - Canadian General Electric

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 20.88 x 29.88 x 13.25 inch / 530 x 759 x 337 mm

• Notes

• The Canadian General Electric model C-604 is a 6 tube broadcast receiver with built-in 45 rpm record changer. It is designed for 25 or 60 Hz depending on nameplate.

  The pickup is the crystal type. There is an auxilary power receptacle on the rear panel. It uses an internal loop antenna. The loudspeaker is 6" x 9" eliptical.

  It is available in Walnut or Korina colour.

• Mentioned in
• General Electric Radio and Television Service Manual 1945-1949 (Pages 215-219)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
