C-751

C-751 ; Canadian General (ID = 200765) Radio
C-751 ; Canadian General (ID = 1695905) Radio C-751 ; Canadian General (ID = 1414577) Radio
C-751 ; Canadian General (ID = 200766) Radio C-751 ; Canadian General (ID = 1695904) Radio
C-751 ; Canadian General (ID = 2218438) Radio
Use red slider bar for more.
C-751 ; Canadian General (ID = 1695905) Radio
Canadian General: C-751 [Radio] ID = 1695905 933x670
Select picture or schematic to display from thumbnails on the right and click for download.
For model C-751, Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON:
From a Craigslist advertisement.

Country:  Canada
Manufacturer / Brand:  Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / Either AC: 25-60Hz, 105-125V or DC: 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: C-751 - Canadian General Electric
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 9 x 6 x 5.5 inch / 229 x 152 x 140 mm
Notes

The General Electric model C-751 is an AC/DC operated 5 tube BC band receiver. The BC band frequency tuning range is 540 to 1720kHz. The tuning control drive ratio is 1:1.

The following models share the same schematics and service data:

Model Cabinet Antenna
C-751 Plastic cabinet, walnut color Antenna coil on chassis
C-751 Plastic cabinet, pink color Antenna coil on chassis
C-751 Plastic cabinet, ivory color Antenna coil on chassis
C-751 Plastic cabinet, orchid color Antenna coil on chassis
C-752H Wooden cabinet with homespun grille cloth Antenna coil on chassis
C-752T Wooden cabinet with tartan grille cloth Antenna coil on chassis
C-752LH Wooden cabinet with homespun grille cloth Loop antenna on the back cover
C-752LT Wooden cabinet with tartan grille cloth Loop antenna on the back cover

WARNING:  One side of the AC line is connected to the chassis.  When servicing this radio, an isolation transformer should be used between the power line and the radio.







Mentioned in Table Top Radios Vol. 1 Stein 98 (page 83.)
Literature/Schematics (1) Radio College of Canada, Individual Circuit Service, 1927-1953
Literature/Schematics (2) General Electric Radio and Television Service Manual 1945-1949 (Pages 220-223)

Model page created by Vitor Oliveira. See "Data change" for further contributors.
