• Country
• Canada

• Manufacturer / Brand
• Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 94019

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 1R5 1N5G 1N5G 1H5G 1A5G 1G6G

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Storage and/or dry batteries / 1.5; 2 x 45 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• from Radiomuseum.org
• Model: JK60-B - Canadian General Electric

• Literature/Schematics (1)
• Radio College of Canada, Individual Circuit Service, 1927-1953

• Author
• Model page created by Vitor Oliveira. See "Data change" for further contributors.
