4E21X Ch= 4E2X

4E21X Ch= 4E2X; Canadian Admiral Co. (ID = 2260176) Radio
Use red slider bar for more.
4E21X Ch= 4E2X; Canadian Admiral Co. (ID = 2260176) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  Canadian Admiral Co. Ltd; Long Branch, Ont.
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1U4 1U5 3V4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / Either 7.5 & 90 or AC or DC 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 4E21X Ch= 4E2X - Canadian Admiral Co. Ltd; Long
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

The Admiral model 4E21X is a 4-tube line or battery powered portable radio.

Model Colour
4E21X Gray
4E22X Red/White
4E24X Tan/White
4E28X Turquoise/White

See also USA model.

Literature/Schematics (1) Radio College of Canada (RCC) (1957 Supplement 39)

Model page created by Tom Seeger. See "Data change" for further contributors.
