4L24X Ch= 4L2X
Use red slider bar for more.
Canadian Admiral Co.: 4L24X Ch= 4L2X [Radio] ID = 2254874 889x664
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1957 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: 12AU6 12AV6 50C5 35W4 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Tuned circuits | 4 AM circuit(s) | ||||||||||||
| Wave bands | Broadcast only (MW). | ||||||||||||
| Details | |||||||||||||
| Power type and voltage | AC/DC-set / 117 Volt | ||||||||||||
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm | ||||||||||||
| Power out | |||||||||||||
| from Radiomuseum.org | Model: 4L24X Ch= 4L2X - Canadian Admiral Co. Ltd; Long | ||||||||||||
| Material | Plastics (no bakelite or catalin) | ||||||||||||
| Shape | Tablemodel without push buttons, Mantel/Midget/Compact up to 14 | ||||||||||||
| Notes | The Canadian Admiral model 4L24X is a 4-tube table radio for broadcast reception. Has internal loop antenna.
|
||||||||||||
| Literature/Schematics (1) | Radio College of Canada (RCC) (1957 Supplement 41) |
Model page created by Tom Seeger. See "Data change" for further contributors.
