| Year: 1949 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s) |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast only (MW). |
| Details | Record Player (perh.Changer) |
| Power type and voltage | Alternating Current supply (AC) / 117 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm |
| Power out | |
| from Radiomuseum.org | Model: 5C15 Ch= 5C1 - Canadian Admiral Co. Ltd; Long |
| Notes | Built-in loop antenna. |
| Circuit diagram reference | Radio College of Canada |
| Mentioned in | RCC Admiral Supplement Pages 3, 9 |
