For model 5J21X Ch= 5J2, Canadian Admiral Co. Ltd; Long Branch, Ont.:
Picture from Rosemary Swanston.

Country:  Canada
Manufacturer / Brand:  Canadian Admiral Co. Ltd; Long Branch, Ont.
Year: 1951 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 5J21X Ch= 5J2 - Canadian Admiral Co. Ltd; Long
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Notes

The Admiral model 5J21X is a 5-tube table radio for standard broadcast reception. Has internal loop antenna.

Literature/Schematics (1) Radio College of Canada (RCC) (Supplement 25)
