6A22 Ch= 6A2

6A22 Ch= 6A2; Canadian Admiral Co. (ID = 810523) Radio

6A22 Ch= 6A2; Canadian Admiral Co. (ID = 810524) Radio
Use red slider bar for more.
6A22 Ch= 6A2; Canadian Admiral Co. (ID = 810523) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  Canadian Admiral Co. Ltd; Long Branch, Ont.
Year: 1950 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12SK7 12SA7 12SK7 12SQ7 35L6GT 35Z5GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 6A22 Ch= 6A2 - Canadian Admiral Co. Ltd; Long
Material Plastics (no bakelite or catalin)
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Notes Built-in loop antenna.
Circuit diagram reference Radio College of Canada
Mentioned in RCC Admiral Supplement Pages 7, 8
