Capehart 10 Ch= C-312; Farnsworth (ID = 953117) Radio
Farnsworth: Capehart 10 Ch= C-312 [Radio] ID = 953117 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Capehart 10 Ch= C-312, Farnsworth Television & Radio Corp. - see also Capehart:
USA_CAPEHART_Model_10_Ca.1952

Country:  United States of America (USA)
Manufacturer / Brand:  Farnsworth Television & Radio Corp. - see also Capehart
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1U4 1U5 3V4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 67.5 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Capehart 10 Ch= C-312 - Farnsworth Television & Radio
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 7.9 x 5.6 x 2.3 inch / 201 x 142 x 58 mm
Notes The Capehart-Farnsworth model 10 with chassis C-312 was available in colors Green, Taupe and Burgundy.
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Beitman Radio Diagrams Vol. 12, 1952
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965
Literature/Schematics (1) Rider's Perpetual, Volume 23 (last) = covering up to 1954 (and Photofact Date 5-52, set 166, folder 7)
