LCD Color Television TV-7700 - TV-7700Q

LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039351) Television LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039352) Television
LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039353) Television LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039354) Television
LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039355) Television LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 1842753) Television
LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 1842754) Television LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 1842755) Television
LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 1842756) Television LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 1842757) Television
Use red slider bar for more.
LCD Color Television TV-7700 - TV-7700Q; CASIO Computer Co., (ID = 2039351) Television
CASIO Computer Co.,: LCD Color Television TV-7700 - TV-7700Q [Television] ID = 2039351 1024x1012
Select picture or schematic to display from thumbnails on the right and click for download.
For model LCD Color Television TV-7700 - TV-7700Q, CASIO Computer Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  CASIO Computer Co., Ltd.; Tokyo
Year: 1993 Category: Television Receiver (TV) or Monitor
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Batteries / addl. power jack / AA: 6 x 1,5 / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 1.4 inch = 3.6 cm
Power out
from Radiomuseum.org Model: LCD Color Television TV-7700 - TV-7700Q - CASIO Computer Co., Ltd.;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 118 x 105 x 63 mm / 4.6 x 4.1 x 2.5 inch
Notes

TFT LCD panel Sharp, 3" screen size 62x45mm, fluorescent tube backlight, power consumption 4.5W, CCIR PAL B/G, H or UK I, external audio/video Input.

Net weight (2.2 lb = 1 kg) 0.360 kg / 0 lb 12.7 oz (0.793 lb)
Mentioned in - - Manufacturers Literature
