- Country
- United States of America (USA)
- Manufacturer / Brand
- CBS-Columbia Inc.; New York, NY
- Year
- 1954/1955
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 161026
-
- alternative name: CBS Electronics || Columbia Phonographs || Columbia Records
Advert ~1955
Advert ~1955
Advert ~1955
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 45
- Valves / Tubes
- 6T4 6BZ7 6U8 6CB6 6CB6 6CB6 6CB6 6CL6 6CL6 6AN8 6AN8 6AN8 6AU6 6AU6 6AL5 6AV6 6AQ5 12AT7 12AT7 6BL7GT 6AL5 12AU7 6CU6 6CU6 6AU4GT 6AU4GT 3A3 3A3 3A3 6BD4A 6BL7GT 6BL7GT 6BL7GT 6AN8 6CB6 6AL5 6AN8 6BY6 6BY6 6AN8 12BH7 12BH7 12BH7 6BC7 19VP22
- Main principle
- Superhet with RF-stage; ZF/IF 45750/41250 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 9.5 inch = 24.1 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 205C2 - CBS-Columbia Inc.; New York,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 34.25 x 42.7 x 27 inch / 870 x 1085 x 686 mm
- Notes
-
CBS-Columbia model 205C2 is a 21” color TV with US standard VHF tuner channels 2 thru
13, and 14 thru 83 UHF. Equipped with chassis VHF- UHF-tuner 69000621 and picture tube 19VP22.
