C1164M

C1164M ; CBS-Columbia Inc.; (ID = 521508) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521509) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521510) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521511) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521512) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521513) Radio

C1164M ; CBS-Columbia Inc.; (ID = 521514) Radio
C1164M ; CBS-Columbia Inc.; (ID = 521507) Radio
Use red slider bar for more.
C1164M ; CBS-Columbia Inc.; (ID = 521507) Radio
CBS-Columbia Inc.;: C1164M [Radio] ID = 521507 666x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model C1164M, CBS-Columbia Inc.; New York, NY:
Sams photofact.

Country:  United States of America (USA)
Manufacturer / Brand:  CBS-Columbia Inc.; New York, NY
alternative name

CBS Electronics || Columbia Phonographs || Columbia Records
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: ECC85 6AU6A 6BA6 6BE6 6BA6 6AU6A 6AL5 7026 7025 6BQ5 6BQ5 5Y3GT
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker 6 Loudspeakers
Power out
from Radiomuseum.org Model: C1164M - CBS-Columbia Inc.; New York,
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes AC operated AM - FM receiver with stereo amplifier and 4 speed automatic record changer. Sams photofact set 506 folder 9 date 11-60 features the CBS models C1164B, C1164M and C1164W as the same schematic.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 506 folder 9 date 11-60)

Model page created by Peter Hoddow. See "Data change" for further contributors.
