Columbia C-611
CBS-Columbia Inc.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- CBS-Columbia Inc.; New York, NY
- Year
- 1961
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 145259
-
- alternative name: CBS Electronics || Columbia Phonographs || Columbia Records
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- AC/DC-set / 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Columbia C-611 - CBS-Columbia Inc.; New York,
- Shape
- Tablemodel, low profile (big size).
- Notes
- Diode Rectifier.
Manufacturer: Columbia Phonographs, Dept. of CBS Electronics, 405 Park Ave., New York, N. Y.
The Columbia Model C-611 is an AC/DC Operated 6 Tube FM-AM Receiver.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 7-62, Set 587, Folder 5)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
