Digital Compact Disc Player 780CD

CEC (C.E.C.) Chuo Denki Co.; Tokyo, Saitama

  • Year
  • 1991
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 273086

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Digital Compact Disc Player 780CD - CEC C.E.C. Chuo Denki Co.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 435 x 90 x 290 mm / 17.1 x 3.5 x 11.4 inch
  • Notes
  • CEC Frontloading Digital Compact Disc Player Model 780CD.
    Digital converter: LC7881, 16-bit, 4 x oversampling
    CD Mechanism: SF-P1
    Frequency response: 20Hz to 18kHz
    Signal to Noise Ratio: 80dB
    Channel separation: 75dB
    Total harmonic distortion: 0.07%
    Line output: 2V

  • Net weight (2.2 lb = 1 kg)
  • 3.4 kg / 7 lb 7.8 oz (7.489 lb)
  • Price in first year of sale
  • 200.00 GBP
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
