• Country
• Sweden

• Manufacturer / Brand
• Centrum-Radio, Gylling & Co.; Stockholm

• Year
• 1964 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 164379

• • Brand: Gylling

• Number of Transistors
• 8

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 1 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 502 - Centrum-Radio, Gylling & Co.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 265 x 165 x 105 mm / 10.4 x 6.5 x 4.1 inch

• Net weight (2.2 lb = 1 kg)
• 1.850 kg / 4 lb 1.2 oz (4.075 lb)

• Author
• Model page created by Volker Potthast. See "Data change" for further contributors.
