6 Transistor Cordless 6510 (Japan 704)

• Country
• United States of America (USA)

• Manufacturer / Brand
• Channel Master Corp.; USA

• Year
• 1960 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 158554

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• 2SA52 2SA49 2SA53 2SB54 2SB56 2SB56

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / D: 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 6 Transistor Cordless 6510 - Channel Master Corp.; USA

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 12.75 x 5.75 x 5 inch / 324 x 146 x 127 mm

• Notes

• Loudspeaker 4 Ω.
  High - low tone switch. Made in Japan.

  See also Sanyo 6S-08 with additional SW band reception.

  Civil Defense marks on station plate.

  Made in Japan 704

• Price in first year of sale
• 42.95 $

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 549 Folder 6 Date10-61)

• Literature/Schematics (2)
• Collector's Guide To TrR1 Bunis trans.94 (Model info and picture on page 60)

• Literature/Schematics (3)
• Transistor Radios (Model info on page 32)

• Author
• Model page created by Albert Weiss. See "Data change" for further contributors.
