Oszilloskop EO1013T

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 731332) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 731333) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 731334) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 731337) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732057) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732058) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732059) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732060) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732061) Equipment

Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 732065) Equipment
Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 357364) Equipment Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 469410) Equipment
Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 469411) Equipment
Use red slider bar for more.
Oszilloskop EO1013T; Christiani, Dr. Ing. (ID = 357364) Equipment
Christiani, Dr. Ing.: Oszilloskop EO1013T [Equipment] ID = 357364 349x482
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oszilloskop EO1013T, Christiani, Dr. Ing. Paul; Konstanz

Country:  Germany
Manufacturer / Brand:  Christiani, Dr. Ing. Paul; Konstanz
Year: 1973 ? Category: Service- or Lab Equipment
Valves / Tubes 1: D13-480GH
Semiconductors (the count is only for transistors) 44: BC547 BC547 BC547 BC547 BC549 BC549 BC549 BC549 BC549 BC549 BC557 BC557 BD115 BD115 BD115 BD237 BD237 BF177 BF180 BF180 BF199 BF199 BF199 BF199 BF199 BF199 BF199 BF199 BF199 BF338 BF338 BF338 BF494 BF494 BFW10 BFW10 BFW10 BFW10 BSS68 BSV68 BSX20 BSX20 BSX46 BSX46
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oszilloskop EO1013T - Christiani, Dr. Ing. Paul;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 230 x 330 x 360 mm / 9.1 x 13 x 14.2 inch
Notes Y-Verstärkung 10 mV bis 20 V, X-Ablenkung 0,2-50 Hz.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Peter Lokowand. See "Data change" for further contributors.
