• Country
• France

• Manufacturer / Brand
• Clarville (CSF); Paris, Levallois-Perret

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 68641

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6BE6 6BA6 6AT6 EL41 6X4

• Main principle
• Superheterodyne (common); ZF/IF 480 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC)

• Material
• Wooden case

• from Radiomuseum.org
• Model: A52 - Clarville CSF; Paris,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 450 x 280 x 210 mm / 17.7 x 11 x 8.3 inch

• External source of data
• Serge Laffont/Martin Renoth
