R80

R80; Clarville CSF; Paris (ID = 50110) Radio
R80; Clarville CSF; Paris (ID = 1438744) Radio R80; Clarville CSF; Paris (ID = 1438745) Radio
R80; Clarville CSF; Paris (ID = 1438746) Radio R80; Clarville CSF; Paris (ID = 1438748) Radio
R80; Clarville CSF; Paris (ID = 1438749) Radio R80; Clarville CSF; Paris (ID = 1438750) Radio
R80; Clarville CSF; Paris (ID = 1438751) Radio R80; Clarville CSF; Paris (ID = 1438752) Radio
R80; Clarville CSF; Paris (ID = 1438753) Radio
Use red slider bar for more.
R80; Clarville CSF; Paris (ID = 1438744) Radio
Clarville CSF; Paris: R80 [Radio] ID = 1438744 933x572
Select picture or schematic to display from thumbnails on the right and click for download.
For model R80, Clarville (CSF); Paris, Levallois-Perret:
Zierringe an zwei Knöpfen fehlen

Country:  France
Manufacturer / Brand:  Clarville (CSF); Paris, Levallois-Perret
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: EK2 EF5 EBC3 EL2 EM1 EL3 EL3 EZ4
Main principle Superheterodyne (common); ZF/IF 472 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 120; 130; 220; 230 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: R80 - Clarville CSF; Paris,
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 540 x 335 x 275 mm / 21.3 x 13.2 x 10.8 inch
Notes

Étage sortie push-pull avec deux EL3.

Net weight (2.2 lb = 1 kg) 17 kg / 37 lb 7.1 oz (37.445 lb)
External source of data Serge Laffont/Martin Renoth
Literature/Schematics (1) -- Schematic
Literature/Schematics (2) Le grand livre de la TSF (Doctsf Ref 334)
