- Country
- Great Britain (UK)
- Manufacturer / Brand
- Co-operative Wholesale Society (CWS) - Defiant; Manchester
- Year
- 1965
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 109339
-
- Brand: Defiant
Defiant A55 BS in black and cream
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 3 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Defiant A55BS - Co-operative Wholesale Society
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 290 x 230 x 100 mm / 11.4 x 9.1 x 3.9 inch
- Notes
- Portable radio with MW bandspread. Sockets for car aerial, tape, & earphone. Battery type PP9.
- Source of data
- -- Collector info (Sammler)
- Circuit diagram reference
- Radio and TV Servicing books (R&TVS) book
- Mentioned in
- Radio! Radio!, Hill. 1996
- Author
- Model page created by John Koster. See "Data change" for further contributors.
