For model Defiant A5, Co-operative Wholesale Society (CWS) - Defiant; Manchester:
My 1959 Defiant A5 MW/LW 6 transistor portable radio in its black polkadot rexine covered wooden case.
Country:  Great Britain (UK)
Manufacturer / Brand:  Co-operative Wholesale Society (CWS) - Defiant; Manchester
Year: 1959 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: XA102 XA101 XA101 XB103 XC101 XC101
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast (MW) and Long Wave.
Power type and voltage Dry Batteries / 2 × 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 0.25 W (unknown quality)
from Model: Defiant A5 - Co-operative Wholesale Society
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 10.3 x 8 x 4 inch / 262 x 203 x 102 mm
Notes Alternative transistors ; Mullard OC44, 2× OC45, OC81D, 2× OC81. Socket for external aerial.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Price in first year of sale 19.00 GBP
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader sheet 1607
Literature/Schematics (2) ERT service chart 1269

Model page created by Peter Hoddow. See "Data change" for further contributors.
