Superhet Seven 356
Columbia Graphophone Co.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Columbia Graphophone Co.; London
- Year
- 1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 137670
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Superhet Seven 356 - Columbia Graphophone Co.;
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Notes
- Same chassis as in the Marconiphone 256 table radio.
- Price in first year of sale
- 25.00 GBP
- Source of data
- Wireless World (The), London (WW, 79)
- Literature/Schematics (1)
- Trader sheet 700
- Author
- Model page created by Roy Johnson. See "Data change" for further contributors.
