Tube Checker TC-10

• Country
• United States of America (USA)

• Manufacturer / Brand
• Commercial Trades Institute; Chicago (IL)

• Year
• 1955 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 131116

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Tube Checker TC-10 - Commercial Trades Institute;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 14 x 11 x 0 inch / 356 x 279 x 0 mm

• Notes
• Commercial Trades Institute TC-10 Tube Checker; One instrument, manual test voltage adjustment, four tube sockets.

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
