Portable Radio 1K442

Portable Radio 1K442; Concord Radio Corp.; (ID = 1816064) Radio
Use red slider bar for more.
Portable Radio 1K442; Concord Radio Corp.; (ID = 1816064) Radio
Concord Radio Corp.;: Portable Radio 1K442 [Radio] ID = 1816064 1400x914
Select picture or schematic to display from thumbnails on the right and click for download.
For model Portable Radio 1K442, Concord Radio Corp.; Chicago:
Concord Advertise

Country:  United States of America (USA)
Manufacturer / Brand:  Concord Radio Corp.; Chicago
Year: 1950 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1T4 1S5 3S4
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 2 x 1,5 / 1 x 67,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out
from Radiomuseum.org Model: Portable Radio 1K442 - Concord Radio Corp.; Chicago
Material Leather / canvas / plastic - over other material
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 7 x 9.75 x 2.75 inch / 178 x 248 x 70 mm
Notes

Concord Portable AM Radio Model 1K442.
Looks like a leather-bound book.
Durably bound in rugged simulated leather.
Built-In antenna

Net weight (2.2 lb = 1 kg) 4.5 lb (4 lb 8 oz) / 2.043 kg
Price in first year of sale 14.95 USD
Mentioned in -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from Concord Radio Corp.; Chicago
Here you find 64 models, 31 with images and 60 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
