For model 2 Band All Transistor MW/SW Solid State CR-23 (Japan 109), Coney Onkyo Co. Ltd. (Conion); Kobe

Country:  Japan
Manufacturer / Brand:  Coney Onkyo Co. Ltd. (Conion); Kobe
Year: 1963 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SC829 2SA102 2SA101 2SA221 2SB186 2SB186 2SB187 2SB187
Main principle Superheterodyne (common)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: 2 Band All Transistor MW/SW Solid State CR-23 - Coney Onkyo Co. Ltd. Conion;
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 185 x 100 x 45 mm / 7.3 x 3.9 x 1.8 inch
Notes

SW : 3.2 - 12 MHz

Made in Japan 109

Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)

Model page created by José Manuel Silvestre. See "Data change" for further contributors.
