High-Fidelity All Transistor Deluxe CR-61 (Japan 109)

High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623477) Radio High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623484) Radio
High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623480) Radio High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623478) Radio
High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623479) Radio High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623481) Radio
High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623482) Radio High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623483) Radio
Use red slider bar for more.
High-Fidelity All Transistor Deluxe CR-61 ; Coney Onkyo Co. Ltd. (ID = 623477) Radio
Coney Onkyo Co. Ltd.: High-Fidelity All Transistor Deluxe CR-61 [Radio] ID = 623477 786x619
Select picture or schematic to display from thumbnails on the right and click for download.
For model High-Fidelity All Transistor Deluxe CR-61 (Japan 109), Coney Onkyo Co. Ltd. (Conion); Kobe:
Kaunas Lithuania

Country:  Japan
Manufacturer / Brand:  Coney Onkyo Co. Ltd. (Conion); Kobe
Year: 1963 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: High-Fidelity All Transistor Deluxe CR-61 - Coney Onkyo Co. Ltd. Conion;
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 255 x 145 x 100 mm / 10 x 5.7 x 3.9 inch
Notes

Radio set was popular in Greece, Crete island and surroundings in the 1960's.

Made in Japan 109







Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)

Model page created by Zenonas Langaitis. See "Data change" for further contributors.
