• Year
  • 1962 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 266744

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 4
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Dry Batteries / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 4 Transistor Phonograph PH-421 - Continental Merchandise Co.
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 8 x 4 x 2 inch / 203 x 102 x 51 mm
  • Notes
  • Made in Japan

  • Net weight (2.2 lb = 1 kg)
  • 3 lb (3 lb 0 oz) / 1.362 kg
  • Author
  • Model page created by Joao Forte. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model 4 Transistor Phonograph is part of the collections of the following members.
