• Year
  • 1972 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 315612

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 125; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 10 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: E-6420 - Cosmo S.A., Industrias;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 420 x 140 x 295 mm / 16.5 x 5.5 x 11.6 inch
  • Notes
  • Industrias Cosmo, S.A. Tocadiscos estereofónico manual E-6420 (CE-6420)

    • Tocadiscos (plato)  modelo CT-0600 tipo SB-0601 de 4 velocidades
    • Cápsula cristal tipo TB-0120
    • Aguja de zafiro TC-0014
    • Salidas para altavoces externos Z= 16 Ω. Bafles opcionales.

    Véase nota acerca de la nomenclatura usada por Cosmo S.A.

  • Net weight (2.2 lb = 1 kg)
  • 5.8 kg / 12 lb 12.4 oz (12.775 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
