464 black

Cossor, A.C.; London

Data

Forum

Pictures

Collections

Country
Great Britain (UK)

Manufacturer / Brand
Cossor, A.C.; London

Year
1946

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
79028

Schematics

464; Cossor, A.C.; London (ID = 530032) Radio — Cossor, A.C.; London 464 (3)

464; Cossor, A.C.; London (ID = 530033) Radio — Cossor, A.C.; London 464 (3)

464; Cossor, A.C.; London (ID = 1251886) Radio — Cossor, A.C.; London 464 (3)

464; Cossor, A.C.; London (ID = 1251887) Radio — Cossor, A.C.; London 464 (3)

464; Cossor, A.C.; London (ID = 192893) Radio — Cossor, A.C.; London 464 (1)

464; Cossor, A.C.; London (ID = 192896) Radio — Cossor, A.C.; London 464 (1)

464; Cossor, A.C.; London (ID = 201586) Radio — Cossor, A.C.; London 464 (2)

464; Cossor, A.C.; London (ID = 201587) Radio — Cossor, A.C.; London 464 (2)

464; Cossor, A.C.; London (ID = 1042775) Radio — Cossor, A.C.; London 464 (1)

464; Cossor, A.C.; London (ID = 2038310) Radio — Cossor, A.C.; London 464 (1)
Cossor 464 chassis before restoration.

464; Cossor, A.C.; London (ID = 2038311) Radio — Cossor, A.C.; London 464 (1)
Chassis view after restoration.

464; Cossor, A.C.; London (ID = 2038312) Radio — Cossor, A.C.; London 464 (1)
Under chassis view after restoration.

464; Cossor, A.C.; London (ID = 2038313) Radio — Cossor, A.C.; London 464 (1)
Label inside cabinet showing valve types.

464; Cossor, A.C.; London (ID = 2038314) Radio — Cossor, A.C.; London 464 (1)
Under chassis before restoration.

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
5

Valves / Tubes
OM10 OM6 OM4 6V6G 6X5G

Main principle
Superheterodyne (common); ZF/IF 465 kHz

Tuned circuits
6 AM circuit(s)

Wave bands
Broadcast, Long Wave and Short Wave.

Power type and voltage
Alternating Current supply (AC) / 200-255 Volt

Loudspeaker
Permanent or electro-dynamic (moving coil), system not known yet.

Material
Bakelite case

from Radiomuseum.org
Model: 464 [black] - Cossor, A.C.; London

Shape
Tablemodel, low profile (big size).

Dimensions (WHD)
13.5 x 9 x 6.75 inch / 343 x 229 x 171 mm

Notes
Available in black, and (sprayed)green or ivory.

Price in first year of sale
18.00 GBP

Source of data
Radio! Radio!

Literature/Schematics (1)
Cossor Trader Service Sheet, 1946

Literature/Schematics (2)
Trader sheet 775

Author
Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
