• Year
  • 1956
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 130449

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Millivoltmètre MV153 - CRC, Constructions
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 265 x 330 x 220 mm / 10.4 x 13 x 8.7 inch
  • Notes
  • Millivoltmètre Amplificateur, Bande de fréquence 20Hz à 400Khz, Tension CA de 100 MicroVeff à 300 Veff, impédance d'entrée > 1 MOhm, Déviation totale pour 1 mVeff., Galvanomètre de 150mm à 3 échelles (Volts, Décibels, Décinépers) précision supérieure à 5% du maximun de l'échelle, Tropicalisé. the schematic screwed on the cabinet indicates 3 dates: 23/10/56 amd the modifications:13/02/58 and 18/2/59
  • Net weight (2.2 lb = 1 kg)
  • 11 kg / 24 lb 3.7 oz (24.229 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Toute la radio 1957)
  • Author
  • Model page created by Raynal Aufils. See "Data change" for further contributors.
