For model 27 BD, Crosley Radio Corp.; Cincinnati (OH)

Country:  United States of America (USA)
Manufacturer / Brand:  Crosley Radio Corp.; Cincinnati (OH)
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1A7GT 1N5GT 1H5GT 1T5GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / 110; 6, 75 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 inch = 14 cm
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: 27 BD - Crosley Radio Corp.;
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 13.2 x 12 x 6.25 inch / 335 x 305 x 159 mm
Price in first year of sale 19.95 $
Collectors' prices
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Literature/Schematics (1) Crosley 20th Anniversary Special 1941 catalogue
Literature/Schematics (3) Crosley Folder No. 2901, Season 1940/41.
